Description
As a popular alternative to our Radius Arm and 4 Link System this Basic Drop Bracket system is designed for the budget minded enthusiast. Application utilizes the stock radius arm. Completing this system is a Trac Bar relocation bracket, Pitman Arm, Sway Bar drops, Add-a-leafs with rear blocks, u bolt kit and more.
Specifications:
| California Proposition 65 | WARNING: Cancer & Reproductive Harm and image |
| Description_ASC | TIRE SIZE – 35/12.50R17 WHEEL – 17X9 W/4 3/4″ BS W/MINOR TRIMMING; TIRE SIZE – 35/12.50R18 WHEEL – 18X9 W/4 3/4″ BS W/MINOR TRIMMING; TIRE SIZE – 35/12.50R20 WHEEL – 20X9 W/5″ BS W/MINOR TRIMMING; 65. MUST USE 17 IN. WHEELS OR LARGER.; 116. DOES NOT FIT BAJA SERIES MODELS.; 168. WILL NOT FIT TRD PRO MODELS |
| Description_ASC | TIRE SIZE-35/12.50R17 WHEEL-17X9 W/4 3/4in. BS W/MINOR TRIMMING; TIRE SIZE-35/12.50R18 WHEEL-18X9 W/4 3/4in. BS W/MINOR TRIMMING; TIRE SIZE-35/12.50R20 WHEEL-20X9 W/5in. BS W/MINOR TRIMMING; 65. MUST USE 17 IN. WHEELS OR LARGER.; 116. DOES NOT FIT BAJA SERIES MODELS.; 168. WILL NOT FIT TRD PRO MODELS |
| Description_DEF | Suspension Lift Kit |
| Description_DES | 6″ BASIC SYS 2016-21 TOYOTA TACOMA 4WD/2WD 6LUG MODEL ONLY |
| Description_DES | Basic Lift System |
| Description_DES | COMPONENT BOX 1 |
| Description_DES | COMPONENT BOX 2 |
| Description_DES | REAR SHOCK EXT BOX |
| Description_DES | TOYOTA 4WD SPACER BOX |
| Description_EXT | 6″ BASIC SYS 2016-21 TOYOTA TACOMA 4WD/2WD 6LUG MODEL ONLY. |
| Description_EXT | Basic Lift System; 6 in. Lift; |
| Description_EXT | Coil Spring Spacer Kit; Front; For 6 in. Lift; For PN[K7019/K7047M/K7006/K7034/K7024/K7047/K7006M/K7019M/K7024M/K7019DL/K7024DL/K7006DL]; |
| Description_EXT | Component Box; Box 1 of 2; For 6 in. Lift; For PN[K7047M/K7048DL/K7049DL/K7047]; |
| Description_EXT | Component Box; Box 2 of 2; For PN[K7047M/K7048DL/K7049DL/K7047]; |
| Description_EXT | Shock Extension; Rear for 6 in. Lift System; |
| Description_FAB | Designed For The Budget Minded Enthusiast |
| Description_FAB | Everything You Will Need To Lift Your Vehicle |
| Description_FAB | Utilizes The Stock Radius Arm |
| Description_INV | Fabtech-6″ BASIC SYS 2016-21 |
| Description_LAB | Proposition 65 |
| Description_MKT | As a popular alternative to our Radius Arm and 4 Link System this Basic Drop Bracket system is designed for the budget minded enthusiast. Application utilizes the stock radius arm. Completing this system is a Trac Bar relocation bracket, Pitman Arm, Sway Bar drops, Add-a-leafs with rear blocks, u bolt kit and more. |
| Description_MKT | Toyota’s 2016 Tacoma has been updated with slight changes to the suspension platform and Fabtech has taken advantage of this by developing new 6in Suspension Systems. This 6in Basic System includes front spacers utilizing the factory Coilover shock while the rear uses factory shocks with extensions. Systems come with Fabtech’s 5/60 Powertrain warranty. Five years or 60,000 mile warranty on the vehicle with a Fabtech’suspension. Estimated installation time- 6-7 hours. Zero holes to drill. Welding required. No driveshaft modification required. |
| Description_SHO | 6″ BASIC SYS 2016-21 |
| Description_SHO | Lift Kit-Suspension |
| height | 16.25 |
| length | 45.5 |
| Lift/Drop Height | 6 in. |
| LTL | N |
| Title | Fabtech 6″ BASIC SYS 2016-21 TOYOTA TACOMA 4WD/2WD 6LUG MODEL ONLY |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | Warning: Cancer and Reproductive Harm-www.P65Warnings.ca.gov. |
| weight | 256.2 |
| width | 32.675 |
